Product Information
Wire Specifications
CONDUCTOR | NOMINAL O.D. | |||||
|---|---|---|---|---|---|---|
| S26A01TX-1.5 | 26 | 0.0159 | 0.404 | 0.0189 | 0.480 | 0.83 |
| S27A01TX-1.5 | 27 | 0.0142 | 0.361 | 0.0172 | 0.437 | 0.66 |
| S28A01TX-1.5 | 28 | 0.0126 | 0.320 | 0.0156 | 0.396 | 0.53 |
| S29A01TX-1.5 | 29 | 0.0113 | 0.287 | 0.0143 | 0.363 | 0.43 |
| S30A01TX-1.5 | 30 | 0.0100 | 0.254 | 0.0130 | 0.330 | 0.34 |
| S31A01TX-1.5 | 31 | 0.0089 | 0.226 | 0.0119 | 0.302 | 0.28 |
| S32A01TX-1.5 | 32 | 0.0080 | 0.203 | 0.0110 | 0.279 | 0.23 |
| S33A01TX-1.5 | 33 | 0.0071 | 0.180 | 0.0101 | 0.257 | 0.18 |
| S34A01TX-1.5 | 34 | 0.0063 | 0.160 | 0.0093 | 0.236 | 0.15 |
| S35A01TX-1.5 | 35 | 0.0056 | 0.142 | 0.0086 | 0.218 | 0.12 |
