Product Information
Wire Specifications
CONDUCTOR | NOMINAL O.D. | |||||
|---|---|---|---|---|---|---|
| S22A01TX-3 | 22 | 0.0253 | 0.643 | 0.0313 | 0.795 | 2.14 |
| S23A01TX-3 | 23 | 0.0226 | 0.574 | 0.0286 | 0.726 | 1.73 |
| S24A01TX-3 | 24 | 0.0201 | 0.511 | 0.0261 | 0.663 | 1.38 |
| S25A01TX-3 | 25 | 0.0179 | 0.455 | 0.0239 | 0.607 | 1.12 |
| S26A01TX-3 | 26 | 0.0159 | 0.404 | 0.0219 | 0.556 | 0.90 |
| S27A01TX-3 | 27 | 0.0142 | 0.361 | 0.0202 | 0.513 | 0.73 |
| S28A01TX-3 | 28 | 0.0126 | 0.320 | 0.0186 | 0.472 | 0.59 |
| S29A01TX-3 | 29 | 0.0113 | 0.287 | 0.0173 | 0.439 | 0.48 |
| S30A01TX-3 | 30 | 0.0100 | 0.254 | 0.0160 | 0.406 | 0.39 |
| S31A01TX-3 | 31 | 0.0089 | 0.226 | 0.0149 | 0.378 | 0.32 |
