Product Information
Wire Specifications
CONDUCTOR | NOMINAL O.D. | |||||
|---|---|---|---|---|---|---|
| S18A01F-3 | 18 | 0.0403 | 1.024 | 0.0463 | 1.176 | 5.31 |
| S18A19F-3 | 18(19/30) | 0.0416 | 1.209 | 0.0385 | 1.361 | 6.33 |
| S20A01F-3 | 20 | 0.0320 | 0.813 | 0.0380 | 0.965 | 3.41 |
| S20A19F-3 | 20(19/32) | 0.0385 | 0.978 | 0.0445 | 1.130 | 4.12 |
| S22A01F-3 | 22 | 0.0253 | 0.643 | 0.0313 | 0.795 | 2.19 |
| S22A19F-3 | 22(19/32) | 0.0296 | 0.749 | 0.0345 | 0.925 | 2.62 |
| S24A01F-3 | 24 | 0.0201 | 0.511 | 0.0261 | 0.663 | 1.43 |
| S24A19F-3 | 24(19/36) | 0.0242 | 0.615 | 0.0302 | 0.767 | 1.71 |
| S25A01F-3 | 25 | 0.0179 | 0.455 | 0.0239 | 0.607 | 1.16 |
| S26A01F-3 | 26 | 0.0159 | 0.483 | 0.0250 | 0.635 | 0.96 |
