Product Information
Wire Specifications
CONDUCTOR | NOMINAL O.D. | |||||
|---|---|---|---|---|---|---|
| S28A01PX-1.5 | 28 | 0.0126 | 0.320 | 0.0156 | 0.396 | 0.54 |
| S29A01PX-1.5 | 29 | 0.0113 | 0.287 | 0.0143 | 0.363 | 0.44 |
| S30A01PX-1.5 | 30 | 0.0100 | 0.254 | 0.0130 | 0.330 | 0.35 |
| S31A01PX-1.5 | 31 | 0.0089 | 0.226 | 0.0119 | 0.302 | 0.29 |
| S32A01PX-1.5 | 32 | 0.0080 | 0.203 | 0.0093 | 0.279 | 0.24 |
| S33A01PX-1.5 | 33 | 0.0071 | 0.180 | 0.0101 | 0.257 | 0.19 |
| S34A01PX-1.5 | 34 | 0.0063 | 0.160 | 0.0093 | 0.236 | 0.15 |
| S35A01PX-1.5 | 35 | 0.0056 | 0.142 | 0.0086 | 0.218 | 0.13 |
| S36A01PX-1.5 | 36 | 0.0050 | 0.127 | 0.0080 | 0.203 | 0.10 |
| S37A01PX-1.5 | 37 | 0.0045 | 0.114 | 0.0075 | 0.191 | 0.09 |
